Details

---

CROSS HATCH CUTTER BASIC KIT: 6 x 3mm (F10713222-5)



The Elcometer 107 Cross Hatch Cutter for adhesion tests provides an instant assessment of the quality of the bond to the substrate.

*Note: If you have any questions, need further information, or require assistance with other model’s price, please don’t hesitate to contact us.

For more details, please contact us on 03-3359 0375.

---

Due to its rugged construction this cross hatch gauge is ideal for thin, thick or tough coatings on all surfaces. An ideal field or laboratory test.

• Robust design
• Large, non slip grip
• Ideal for thin, thick or hard coatings
• A quick change, 4 sided cutter allows adhesion testing on a wide range of coating thicknesses (1mm, 1.5mm, 2mm and 3mm)

The Elcometer 107 Cross Hatch Cutter for adhesion testing is available as a Basic or Full Kit.

Weight	1.2 kg
Dimensions	27 × 21.5 × 6.5 cm

Technical Specification

Part Number	Description	Cutter Type	Coating Thickness:		Certificate
F10713222-1	Elcometer 107 Basic Kit	6 x 1mm	0 – 60μm	0 – 2.4mils
F10713348-6	Elcometer 107 Full Kit with ISO Tape	6 x 1mm	0 – 60μm	0 – 2.4mils
F10713348-1	Elcometer 107 Full Kit with ASTM Tape	6 x 1mm	0 – 50μm	0 – 2.0mils
F10713222-2	Elcometer 107 Basic Kit	11 x 1mm	0 – 50μm	0 – 2.0mils
F10713348-2	Elcometer 107 Full Kit with ASTM Tape	11 x 1mm	0 – 50μm	0 – 2.0mils
F10713222-3	Elcometer 107 Basic Kit	11 x 1.5mm	0 – 90μm*	0 – 3.5mils*
F10713222-4	Elcometer 107 Basic Kit	6 x 2mm	50 – 125μm	2.0 – 5.0mils
F10713348-9	Elcometer 107 Full Kit with ISO Tape	6 x 2mm	61 – 120μm	2.4 – 4.7mils
F10713348-4	Elcometer 107 Cross Hatch Cutter Full Kit with ASTM Tape	6 x 2mm	50 – 125μm	2.0 – 5.0mils
F10713222-5	Elcometer 107 Basic Kit	6 x 3mm	121 – 250μm	5.0 – 10mils
Packing List Basic Kit: Robust handle, cutter, hexagonal wrench, presentation storage case and instructions (together with Classification of Adhesion Test Results chart) Full Kit: Robust handle, cutter, hexagonal wrench, instructions (together with Classification of Adhesion Test Results chart), magnifier (x6 magnification), brush and adhesive tape (either ASTM or ISO tape), all in a plastic ABS carry case

Standards

AS 3894.9, AS 1580.408.4, ASTM D 3359-B, BS 3900-E6, ECCA T6, EN 13523-6, ISO 2409, ISO 16276-2, JIS K 5600-5-6, NF T30-038

BS 3900-E6, ECCA T6, NF T30-038 Standards have been superseded but are still recognised in some industries.
