ELCOMETER 410 ANEMOMETER (WIND SPEED METER) (G410-1)

The Elcometer 410 Anemometer is a portable, pocket sized instrument for taking accurate readings of wind speed.

*Note: If you have any questions, need further information, or require assistance with other model’s price, please don’t hesitate to contact us.

For more details, please contact us on 03-3359 0375.

---

The lightweight impeller with high precision jewel bearings provides very accurate airflow measurements even at low speeds. The anemometer’s impeller can easily be replaced without the need to return the unit to Elcometer.

The wind speed can be displayed in various measurement units; indicating current speed, maximum speed or average speed.

• Rugged and durable: The Elcometer Anemometer is made from high impact injection moulded plastic and corrosion resistant materials.
• Waterproof: Waterproof equivalent to IP67 with fully sealed electronics. Will also float in water if dropped.
• Clear LCD Display: Easy to read, large 9mm digits.
• Choice of measurement units:
  • Beaufort Force
  • Knots
  • Kilometres per hour
  • Metres per second
  • Miles per hour
  • Feet per minute

Weight	0.102 kg
Dimensions	12.2 × 4.6 × 2.6 cm

Technical Specification

Part Number	Description
G410-1	Elcometer 410 Anemometer
Functions	Current wind speed, Average 3 second wind speed, Maximum wind gust, Data Hold
Measurement Units	Knots (kt), metres per second (m/s), kilometres per hour (km/h), miles per hour (mph), feet per minute (ft/min) and Beaufort Force (B)
Operating Range	0.4m/s to 60m/s (0.8 to 135.0mph)
Specification Range	0.4m/s to 40m/s (0.8 to 89.0mph)
On-axis Accuracy	±3% of reading or least significant digit, whichever is the greater
Off-axis Response	-1% at 5º, -2% at 10º, -3% at 15º
Calibration Drift	<1% after 100 hours operation at 7m/s
Resolution	0.1 kt, m/s, km/h, mph. 1 ft/min below 1999 ft/min, 10 ft/min above 2000 ft/min. 1 Beaufort (0 to 12)
Operating Temperature	-10ºC to +55ºC (14ºF to 131ºF)
Storage Temperature	-30ºC to +60ºC (-22ºF to 140ºF)
Power Supply	1 x CR2032 battery
Battery Life	Approximately 300 hours
Auto Switch Off	45 minutes after last key press
Dimensions	Instrument Only: 122 x 42 x 20mm (4.8 x 1.6 x 0.8”) Instrument and Protective Cover: 122 x 46 x 26mm (4.8 x 1.8 x 1”)
Weight	Instrument Only: 65g (2.3oz) Instrument and Protective Cover: 102g (3.6oz)
Packing List	Elcometer 410 Anemometer, protective cover, lanyard, 1 x CR2032 battery and operating instructions
