Details

---

The Elcometer 4 Gap Film Applicators are precision engineered from hardened stainless steel to provide four film thicknesses in one gauge.

Simply rotate the applicator to the required thickness, fill the reservoir with the test coating and draw down a uniform stripe.

The Elcometer 3508 is supplied with two reservoirs, ideal for preparing samples for the Elcometer 1720 Abrasion and Washability Testers or for comparing two coatings simultaneously.

Technical Specification

Part Number	Model	Film Thickness		Film Width*
Metric		μm	mils	mm	inches
K0003560M201	Elcometer 3560/1 4 Gap Applicator with Reservoirs	30, 60, 90, 120	1, 2, 3, 4	60	2
K0003560M202	Elcometer 3560/2 4 Gap Applicator with Reservoirs	50, 100, 150, 200	2, 4, 6, 8	60	2
K0003508M001	Elcometer 3508/1 4 Gap Applicator with Reservoirs	100, 150, 200, 250	4, 6, 8, 10	2 x 50	2 x 2
