Details

---

IP protection category: IP 65
Data interface: Integrated Wireless
DIN 863-1
Measuring range mm 150 – 175 mm
Resolution mm/inch 0.001 / .00005″
Package contains: setting standard (measuring range of 25-50 mm), battery, test certificate, instruction manual, case

Code No.: 4157106


Weight	4 kg
Dimensions	38 × 10 × 6 cm

Product Information

• High contrast digit display
• Stainless spindle is hardened throughout and ground
• Spindle and anvil are carbide-tipped
• Rapid drive
• Ratchet is integrated in the thimble
• Lacquered steel frame, heat insulated

Technical Data

Standard	DIN 863-1
Measuring range mm	150 – 175
Measuring range inch	6 – 7″
Material Contact surface	carbide
Resolution mm/inch	0.001 / .00005″
Error limit µm	7 µm
Battery type	CR 2032 (3V Lithium)
Parallel error in µm	4 µm
Flatness in µm	0.6 µm
Spindle diameter	6.5 mm
Spindle thread pitch_mm	0.5 mm
Measuring force (N)	5 – 10
Dimensions	a 95 mm | b 13 mm | c 182 mm |
